Advantages Production in two or three strokes Reducing of marks through spring loaded hold-down-device Active components are hardened High repeatability through integrated backgauge Functional test and adjustment through test bends - with your sample sheets Suitable For Material thickness up to 4,0 mm minimum inside Ø: 2,5 mm x material thickness for steel and aluminium 3,0 mm x material thickness for stainless steel
Press brake rolla-v dies without scratch, it's best to put the film on the workpiece surface when you bend. and we will recoomend the suitable roll-v die size for you according to the plate you bend.
Shim Style Adjustable Dies Adjustable lower dies could be considered to be one of the most versatile additions to a press brake. With this type of tool, openings can be arranged from 6.35mm to 381mm. Spacers are provided to produce the required opening. Slotted spacers allow for easy removal to change the die opening. When not in use, spacers are positioned at sides of the die block. These dies can be furnished in solid lengths or sectioned for easier handling.
The stright blade size:835*146*26mm,90degree. the material is 42CrMo4, hardness is HRC47+/-3
The stright blade size:835*175*40mm,60degree. the material is 42CrMo4, hardness is HRC47+/-3
The stright blade size:835*146*26mm,90degree. the material is 42CrMo4, hardness is HRC47+/-3
The Amada press brake tooling straight blade size:835*145*32mm,60degree. the material is 42CrMo4, hardness is HRC47+/-3
The gooseneck punch size:835*197*92mm,88degree. the material is 42CrMo4, hardness is HRC47+/-3. and height 197mm,width 92mm. can be made according to customer's request.
The T-V die size:835*120*60mm,V12,30degree. the material is 42CrMo4, hardness is HRC52-58. and V6,V8,V10,V16,V20,V25 can be made according to customer's request.
The self centering 2V dies, the size is 835*46*50mm,88degree,the weisght is 17kg.and we can make V5-V9,V8-V12,V12-V20,V16-V25 and other V opening according the bending thickness.
In the spring of 2026, the 139th China Import and Export Fair (Canton Fair) concluded successfully in Guangzhou. GOLIN Press Brake Tooling showcased a wide range of high-quality products, fully demonstrating its technical strength and manufacturing capabilities in the field of press brake tooling.
During the exhibition, GOLIN’s booth attracted professional visitors and industry experts from all over the world. The team engaged in in-depth discussions with customers from various countries and regions, not only reaching multiple cooperation intentions but also gaining deeper insights into the diverse global demand for press brake tooling.
At the same time, GOLIN strengthened its connections with global partners through the exhibition, engaging in extensive exchanges on technological development, application prospects, and industry trends of press brake tooling, laying a solid foundation for future international cooperation.
Through this Canton Fair, GOLIN not only gained valuable customer resources but also further enhanced its international brand influence. Looking ahead, the company will continue to uphold a high-quality development strategy, drive innovation in products and technology, and provide better press brake tooling solutions to customers worldwide.
Please read on, stay posted, subscribe, and we welcome you to tell us what you think.
