Advantages Production in two or three strokes Reducing of marks through spring loaded hold-down-device Active components are hardened High repeatability through integrated backgauge Functional test and adjustment through test bends - with your sample sheets Suitable For Material thickness up to 4,0 mm minimum inside Ø: 2,5 mm x material thickness for steel and aluminium 3,0 mm x material thickness for stainless steel
Press brake rolla-v dies without scratch, it's best to put the film on the workpiece surface when you bend. and we will recoomend the suitable roll-v die size for you according to the plate you bend.
Shim Style Adjustable Dies Adjustable lower dies could be considered to be one of the most versatile additions to a press brake. With this type of tool, openings can be arranged from 6.35mm to 381mm. Spacers are provided to produce the required opening. Slotted spacers allow for easy removal to change the die opening. When not in use, spacers are positioned at sides of the die block. These dies can be furnished in solid lengths or sectioned for easier handling.
The stright blade size:835*146*26mm,90degree. the material is 42CrMo4, hardness is HRC47+/-3
The stright blade size:835*175*40mm,60degree. the material is 42CrMo4, hardness is HRC47+/-3
The stright blade size:835*146*26mm,90degree. the material is 42CrMo4, hardness is HRC47+/-3
The Amada press brake tooling straight blade size:835*145*32mm,60degree. the material is 42CrMo4, hardness is HRC47+/-3
The gooseneck punch size:835*197*92mm,88degree. the material is 42CrMo4, hardness is HRC47+/-3. and height 197mm,width 92mm. can be made according to customer's request.
The T-V die size:835*120*60mm,V12,30degree. the material is 42CrMo4, hardness is HRC52-58. and V6,V8,V10,V16,V20,V25 can be made according to customer's request.
The self centering 2V dies, the size is 835*46*50mm,88degree,the weisght is 17kg.and we can make V5-V9,V8-V12,V12-V20,V16-V25 and other V opening according the bending thickness.
We sincerely invite you to attend Phase 1 of the 139th China Import and Export Fair (Canton Fair), which will be held from April 15 to April 19, 2026, in Guangzhou, China.
Golin Tooling will showcase a wide range of high-quality press brake tooling at this exhibition, including Amada-style tooling, non-marking bending tools, multi-V dies, and various customized solutions. We are committed to providing global customers with high-precision, highly durable, and cost-effective press brake tooling products.
You are warmly welcome to visit our booth and learn more about our product advantages and technical capabilities:
Booth No.: 18.1D19
Date: April 15 – April 19, 2026
Venue: China Import and Export Fair Complex, Guangzhou, China
Golin Tooling always adheres to a customer-oriented approach, continuously innovating and improving product quality. We look forward to meeting you in person at the exhibition to discuss cooperation opportunities and explore broader markets together.
